Model		1KVA		2KVA			3KVA
Rated Power		900W/1000W		1800W/2000W			2700W/3000W
Input	Wiring	L+N+PE
	Rated Voltage	208/220/230/240Vac
	Voltage Range	110~300Vac
	Frequency	50/60±6Hz(default),±10Hz( Adjustable)
	Power Factor	≥0.99
	Generator Compatibility	Available
Output	Wiring	L+N+PE
	Rated Voltage	208/220/230/240Vac,Factory Preset:220Vac
	Output Voltage Regulation	±1%
	Frequency	Online Mode: Follow Grid Frequency；Battery Mode:50/60±0.1Hz
	THD	Linear Load≤2%,Non-Linear Load≤5%(PF=0.8)
	Power Factor	0.9/1.0(Optional )
	Switching Time	0ms
	Overload	AC Mode:1102%~110% 30mins then transfer to bypass, 110%~130% 10mins & transfer to bypass, 130%~150% 30s, ≥150% 200ms transfer to bypass, Load≤70% recover to inverter mode.			Battery Mode:102%~109% 1minute backup then shutdown, 110%~130% 10s then shutdown,130%~150% 3s , ≥150% 200ms,(under BAT mode UPS will be closed after 1mins when INV. Turn off)
	Crest Ratio	3:1
Efficiency	Online Mode	94.5%@220Vac		95.5%@220Vac
	Battery Mode	89.5%		91.5%
Battery and Charger	Battery Type	Lead Acid Maintenance Free Battery / Lithium battery
	Standard Model	2PCS		2PCS			6PCS
	Long-run Model	3PCS		6PCS			8PCS
	Battery over Voltage	N*13.65Vdc(1±1%)
	Battery under voltage	10V*N@Load>50%
	Shutdown Protection	Available
	Over-charging Protection	Available
	Charging Form	2 Stages/ 3 Stages Charging
	BAT Abnormal Alarm	Available
	Charging Current	1-12A Adjustable
Communication	Port	RS232( Optional SNMP,USB,EPO)
Environmen	Ambient temperature	0~40℃
	Humidity	20%~95% (No condensing)
	Storage temperature	-15~60℃ (Battery:0~40℃)
	Altitude	The altitude should not exceed 1000m, and the height above 1000m should be reduced to a maximum of 4000m. Refer to IEC62040
	Noise (dB)	≤50db
	D×W×H(mm)	38043888mm
	Net Weight(kgs)	5.6kg	9.5kg	6.15kg		14.5kg	6.25kg	20.30kg
Certification		EN/IEC 61000, EN/IEC 62040, GB/T 7260, GB/T 4943, YD/T1095, TLC

**Product specifications are subject to change without further notice.
